| Model |
Voltaj (v) |
Debi (m³/h) |
|---|---|---|
| AVS-SHV1 | 230 | 600 |
| AVS-SHV2 | 230 | 850 |
| AVS-SHV3 | 230 | 1200 |
| AVS-SHV4 | 230 | 1750 |
| AVS-SHV5 | 230 | 2400 |
| AVS-SHV6 | 230 | 3500 |
| AVS-SHV7 | 230 | 4500 |
| Model | A (mm) | B (mm) | C1 (mm) | D (mm) | E (mm) | F (mm) |
|---|---|---|---|---|---|---|
| AVS-SHV1 | 500mm | 360mm | 920mm | 190mm | 360mm | 500mm |
| AVS-SHV2 | 500mm | 360mm | 1120mm | 190mm | 360mm | 500mm |
| AVS-SHV3 | 500mm | 360mm | 1120mm | 190mm | 360mm | 500mm |
| AVS-SHV4 | 750mm | 360mm | 1120mm | 220mm | 360mm | 750mm |
| AVS-SHV5 | 750mm | 400mm | 1120mm | 240mm | 400mm | 750mm |
| AVS-SHV6 | 750mm | 400mm | 1200mm | 260mm | 400mm | 750mm |
| AVS-SHV7 | 800mm | 500mm | 1300mm | 295mm | 500mm | 800mm |
